Custom Aluminium Sliding Windows Manufacturer

FH80 series-Sliding Aluminium Windows (Non-Thermal Break, Integrated Screen)

Sleek integrated sliding design, smooth operation, reliable security, good sound insulation, solid weather protection, and full Australian compliance — a practical, high-value choice for modern projects worldwide.

Premium 6063-T5 Aluminium

80mm frame with 1.4mm wall thickness for strong, lightweight, durable performance.

Integrated Window & Insect Screen

Seamless aluminium screen sash combined with glass sash for clean design and easy use.

Multi-Layer Brush Seals

Multiple silicone-treated brush strips for excellent airtightness and weather resistance.

Silicone Structural Glazing

Wet-sealed glazing for secure, watertight glass attachment.

Concealed Drainage

Hidden system prevents water ingress while maintaining sleek appearance.

Renowned Sliding Lock

High-quality domestic push-pull lock for secure, smooth daily operation.

Double-Glazed Argon-Filled Tempered Glass

Standard 9mm airspace; optional Low-E, laminated, or frosted for better thermal, UV, and privacy performance.

Strong Sound & Air Performance

Standard 9mm airspace; optional Low-E, laminated, or frosted for better thermal, UV, and privacy performance.

AS 2047 & AS 1288 Compliant

Australian standard aluminium window: Certified to Australian standards for wind, water, air infiltration, and safety glazing.

FH102 Series (Thermal Break, Integrated Screen)

Spacious 152mm profile,integrated screen convenience, smooth secure sliding, good sound insulation, reliable weather protection, and full Australian compliance — a high-performance sliding solution for modern projects worldwide.

Premium 6063-T5 Aluminium

152mm frame with 2mm wall thickness for strong, stable, modern profiles.

Integrated Window & Insect Screen

Seamless aluminium screen + glass sash combo for clean look and easy use.

Multi-Layer Brush Seals

Multiple silicone-treated brushes for excellent airtightness and weather resistance.

Silicone Structural Glazing

Wet-sealed glazing for secure, watertight glass fixing.

Concealed Drainage

Hidden system prevents water ingress with sleek appearance.

Renowned Sliding Lock

High-quality domestic push-pull lock for secure, smooth operation.

Double-Glazed Argon-Filled Tempered Glass

Standard 9mm airspace; optional Low-E, laminated, or frosted for enhanced thermal, UV, and privacy performance.

Superior Air & Sound Performance

Strong airtightness + 9mm glazing for effective noise reduction and energy efficiency.

Hassle-Free Access

Open and clean without removing components.

Fully Customizable Colours

Any standard or RAL shade available.

AS 2047 & AS 1288 Compliant

Certified to Australian standards for wind, water, air, and safety glazing.

FH150 Series (Non-Thermal Break, Integrated Screen)

Wide 150mm profile, integrated screen simplicity, ultra-smooth sliding, robust security, strong thermal & sound performance, reliable weather protection, and full Australian compliance — the heavy-duty sliding choice for large openings and premium projects worldwide.

Premium 6063-T5 Aluminium

150mm frame with heavy-duty 2.0–2.5mm wall thickness for maximum strength and elegant profiles.

Integrated Window & Insect Screen

Seamless aluminium screen + glass sash design for clean aesthetics and convenient operation.

Multi-Layer Brush Seals

Multiple silicone-treated brushes for superior airtightness and weather resistance.

Silicone Structural Glazing

Wet-sealed glazing ensures secure, watertight glass fixing.

Concealed Drainage

Hidden system prevents water buildup with a sleek exterior.

Brand Sliding Lock

High-quality push-pull lock for secure, smooth daily use.

Double-Glazed Argon-Filled Tempered Glass

Standard 15mm airspace; optional Low-E, laminated, or frosted for better thermal, UV, and privacy performance.

Excellent Thermal & Acoustic Performance

Strong airtightness + 15mm glazing delivers superior insulation and noise reduction.

Custom Colours

Any standard or RAL shade available.

AS 2047 & AS 1288 Compliant

Certified to Australian standards for wind, water, air infiltration, and safety glazing.

Custom Aluminium Sliding Windows Manufacturer

Fenghui manufactures custom aluminium sliding windows for apartments, hotels, offices, schools, retail buildings, villas and large residential developments.

Our horizontal sliding window systems combine space-saving operation with durable 6063-T5 aluminium frames, integrated insect screens, double glazing, concealed drainage and project-selected hardware. Thermal-break and non-thermal-break systems are available to meet different climate, budget and energy-performance requirements.

Send us your window schedule or architectural drawings. Our team will help you select the appropriate FH80, FH102 or FH150 series and prepare a project-based quotation.

Custom sizes | Project supply | AS 2047 & AS 1288 options | Global delivery

Glazing Options for Different Performance Targets

Glass selection affects safety, energy performance, acoustic control, privacy and total sash weight. Available options include:

► Double-glazed tempered glass for general thermal performance and safety.
► Low-E insulated glass to reduce heat transfer in conditioned buildings.
► Laminated glass for improved safety and acoustic performance.
► Frosted glass for bathrooms, service areas and privacy-sensitive openings.
► Tinted glass for glare control and architectural appearance.
► Argon-filled insulated glass for improved insulation performance.

Glass thickness and make-up should be confirmed according to window size, design pressure, safety requirements and local building regulations.

Custom Aluminium Sliding Window Options

Standard stock windows do not always match architectural drawings or commercial opening schedules. As an aluminium sliding window manufacturer, Fenghui supports project-specific configurations.

Custom Item	Available Options
Window size	Custom width and height within the selected system’s engineering limits
Opening configuration	Left or right sliding, fixed-and-sliding and multi-panel configurations
Frame system	Thermal-break or non-thermal-break aluminium
Glass	Tempered, double-glazed, Low-E, laminated, clear, tinted or frosted
Frame colour	Standard finishes and project-selected RAL colours
Surface treatment	Powder-coated finishes for different architectural and environmental conditions
Insect screen	Integrated aluminium screen sash
Hardware	Project-selected locks, handles and rollers
Performance	Configured according to thermal, acoustic, wind-load and weather requirements
Accessories	Compatible trims and installation accessories subject to project requirements

Australian-Standard Sliding Window Options

Selected Fenghui sliding window systems are designed and tested for compliance with applicable Australian requirements, including:

AS 2047 for window structural performance, air infiltration and water penetration.
AS 1288 for glass selection and installation in buildings.

Compliance depends on the exact window dimensions, glass configuration, frame system and project design pressure. Buyers should confirm that the supporting test report covers the configuration included in the quotation.

For Australian projects, Fenghui can provide market support through its Melbourne branch. Installation scope should be confirmed separately according to the project location.

Why Work with Fenghui?

Fenghui Group was established in 2000 and combines window manufacturing experience with a broader background in construction, real estate development and building material supply.

► 26+ years of industry experience
► 200,000 m² manufacturing base
► Approximately 100,000 m² annual window and door capacity
► ISO 9001:2015 quality management system
► Thermal-break and non-thermal-break product options
► Custom sizes, glass, colours and configurations
► Project experience in residential and commercial buildings
► Export supply to Australia, New Zealand, Canada, Singapore and the Middle East
► Window and door packages available from one supplier

Explore our complete range of custom aluminium windows or learn more about Fenghui's manufacturing capabilities.

Where to use aluminium glass sliding window

Residential

Kitchens & Bathrooms

Ideal above benchtops or sinks where aluminium sliding window for kitchen installations make outward opening impractical.

Living Areas & Bedrooms

Perfect for maximising natural light and providing controlled airflow throughout your home with aluminium glass sliding window systems.

Patios & Decks

Often used as larger door systems, aluminium sliding window for balcony designs create seamless connections to outdoor living spaces.

New Builds & Renovations

A classic, versatile choice, aluminum frame sliding windows integrate beautifully into both modern and traditional designs.

Commercial

Office Partitions

Commercial aluminum sliding windows create adaptable and light-filled internal divisions within commercial office spaces.

Shop Fronts & Serveries

Ideal for retail environments, aluminum horizontal sliding windows offer easy access and a clear display for goods or services.

Cafes & Restaurants

Frequently used as pass-through windows or to open up dining areas to the outdoors, aluminium glass sliding window systems provide practicality and modern style.

Educational & Healthcare Facilities

Aluminium vertical sliding windows provide practical ventilation and light while maintaining security and accessibility.
